MD45A ASP60 Block High Hardness Tungsten Carbide Cube Cutting Tool
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | MD45A ASP60 Block High Hardness Tungsten Carbide Cube Cutting Tool | Material | Tungsten Carbide |
|---|---|---|---|
| Grade | MD45A,ASP60,MD40A,MD40C Etc. | Size | As Per Customer Request |
| Surface | Bright,polished | Application | Mold,cutting Tool Etc. |
| High Light | High Hardness Tungsten Carbide Cube,Tungsten Carbide Cube Cutting Tool,Bright Tungsten Carbide Block |
||
Product Description
MD45A ASP60 Block High Hardness Tungsten Carbide Cube Cutting Tool
1. Information Of Tungsten Carbide Cube:
Tungsten carbide block is a ceramic material composed of tungsten and carbon elements. It has excellent properties such as high hardness, high wear resistance, high thermal stability and excellent chemical stability, and is widely used in various industrial fields.
2. Main Parameters Of Tungsten Carbide Cube:
| Grade | Co% |
Hardness (HRA) |
Density (g/cm3) | Transverse Rupture Strength (Mpa) | Elastic Modulus (GPa) | Coefficient of Thermal Expansion (10-6/℃) | Application |
| MD16 | 6 | 90.5 | 14.8 | 2800 | 530 | 4.9 | SPCC plate |
| MD10 | 10 | 91.7 | 14.4 | 4300 | 490 | 5.4 | Copper, aluminum and other thin sheets with a thickness less than 0.2mm |
| MD40A | 12 | 88.9 | 14.2 | 3300 | 470 | 5.7 | Cold roling plate,Silicon Steel sheet |
| MD33A | 12 | 90.3 | 14.2 | 4000 | 470 | 5.7 | Cold roling plate(Upper Die) |
| MD45A | 15 | 87.9 | 13.9 | 3200 | 440 | 6.1 | Silicon steel sheet,cold roling plates(Lower Die) |
| MD40B | 12 | 89.5 | 14.2 | 3600 | 470 | 5.7 | Cold roling plate,Silicon Steel sheet |
| MD15 | 12 | 92.5 | 14.1 | 5100 | 460 | 5.8 | Thin sheets of copper, aluminum, stainless steel, etc. |
| MD20 | 13 | 90.6 | 14.1 | 4100 | 460 | 5.8 | Strong versatility, copper, aluminum and other thin sheets |
| MD55 | 20 | 86.4 | 13.5 | 3100 | 390 | 6.8 | Silicon steel sheet(Lower Die) |
3. Application Of Tungsten Carbide Cube:
The use of tungsten carbide block is very extensive, mainly including the following aspects:
Manufacture of cutting tools: Tungsten carbide blocks have extremely high hardness and wear resistance, and can be used to manufacture various cutting tools such as high-speed steel blades, milling cutters, drills, and turning tools.
Manufacture of mining tools: Tungsten carbide blocks can withstand extreme wear and high pressure environments, and are widely used in the manufacture of mining drill bits, rock drills and other tools.
Manufacturing molds: Tungsten carbide blocks can be made into molds of complex shapes for the production of various industrial products, such as injection molding molds, extrusion molds, etc.
Wear-resistant coatings: Tungsten carbide blocks can be made into coatings and coated on the surface of various mechanical equipment to improve their wear resistance and service life.
Used in other fields: Tungsten carbide blocks can also be used in aerospace, nuclear energy, chemical industry and other fields, such as for the manufacture of high-temperature furnaces, reactor components, etc.
In summary, tungsten carbide block is a ceramic material with excellent performance and has a wide range of applications.
