99.95% Polished Molybdenum Electrode Plate For Glass And Rare Earth Industry

Place of Origin China
Brand Name PRM
Certification ISO9001
Model Number custom
Minimum Order Quantity 1kg
Price $50~200/kg
Packaging Details Plywood case
Delivery Time 7~10 work days
Payment Terms T/T
Supply Ability 5000kgs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Molybdenum Electrode Plate For Glass And Rare Earth Industry Polished Molybdenum Plate Material Pure Molybdenum
Purity 99.95% Surface Polished
Thickness 3~10mm Width 50~500mm
Length 150~1000mm Standard ASTM B386
High Light

Polished Molybdenum Electrode Plate

,

Rare Earth Industry Molybdenum Plate

,

Glass Molybdenum Electrode Plate

Leave a Message
Product Description

Molybdenum Electrode Plate For Glass And Rare Earth Industry 99.95% Polished Molybdenum Plate



1. Summary Of Molybdenum Electrode Plate For Glass And Rare Earth Industry:



The molybdenum plate is dark brown, and if it is washed with alkali, it will have a silver-gray metallic luster. It can be produced according to the width and thickness provided by the user. Thickness > 0.7mm shall be supplied in hot-rolled state, and plates with thickness < 0.7mm shall be supplied in cold-rolled or surface-cleaned state.



The molybdenum plate used as electrode material is generally more than 3 mm thick, and the surface will be polished or polished.



Molybdenum electrode is a molybdenum electrode material, using its unique advantages, temperature resistance, continuous surface, good electrical conductivity, stable edge, excellent corrosion resistance - to improve its overall quality and service life. Molybdenum electrode is silver gray metallic luster. This is all kinds of forged intermediate frequency furnaces after isostatic sintering, then turning, rolling, planning and grinding.



99.95% Polished Molybdenum Electrode Plate For Glass And Rare Earth Industry 099.95% Polished Molybdenum Electrode Plate For Glass And Rare Earth Industry 1



2. Size of Molybdenum Electrode Plate For Glass And Rare Earth Industry:



Name Thickness(mm) Width max.(mm) Length max.(mm)
Molybdenum sheet 0.2~0.3 650 2500
Molybdenum sheet 0.3~0.5 700 3000
Molybdenum sheet 0.5~1.0 750 3500
Molybdenum sheet 1.0~2.0 650 3500
Molybdenum plate 2.0~3.0 600 3000
Molybdenum plate >3.0 600 L



Description Grade Density
g/cm3
Size (mm) Application
Large Size High temperature molybdenum plate, molybdenum alloy sheet Mo-La
TZM
>9.8 (20-40) x (90-240) x (200-600) Good high temperature performance and machinability
High purity molybdenum sheet Mo 10.2 Suitable for rolling pure molybdenum sheet
Small Size High purity molybdenum sheet Mo 16 x 16 x 160 Suitable for rolling molybdenum foil and molybdenum disc



3. Chemical of Molybdenum Electrode Plate For Glass And Rare Earth Industry:



Chemical content as per ASTM B386:



Purity >99.95%



Element Composition %
Grade
361(Mo-1) 364(TZM) 366(Mo-30%W)
C 0.01 max. 0.01~0.04 0.03 max.
O,max. 0.007 0.03 0.0025
N,max. 0.002 0.002 0.002
Fe, max. 0.01 0.01 0.01
Ni, max. 0.005 0.005 0.005
Si, max. 0.01 0.005 0.01
Ti 0.4~0.55
W     27~33
Zr   0.06~0.12
Mo Remain Remain Remain
