95%W Tungsten Nickel Copper Rod W Ni Cu Alloy Polished Radiation Detectors Alloy Rod

Place of Origin China
Brand Name PRM
Certification ISO9001
Model Number custom
Minimum Order Quantity 1kg
Price $50~200/kg
Packaging Details plywood case
Delivery Time 15~20 work days
Payment Terms T/T
Supply Ability 2000kgs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name 95%W Tungsten Nickel Copper W-Ni-Cu Alloy Rod Material Tungsten Nickel Copper Alloy
W Content 95% Grade W95-Ni-Cu
Shape Rod Diameter 5~150mm
Length ≤ 1000mm Standard ASTM B777
High Light

95%W Tungsten Nickel Copper Rod

,

polished Tungsten Nickel Copper Rod

,

150mm W Ni Cu

Leave a Message
Product Description

95%W Tungsten Nickel Copper W-Ni-Cu Alloy Rod



1. Tungsten Nickel Copper W-Ni-Cu Alloy Rod 95%W Specifications:



Diameter: 5~150mm

Length: <1000mm

Surface: black/ alkaline washing/ polished

Density: 15.2~19.0 g/cm3



We are able to process a variety of shaped parts based on a customer's drawing.

Chemcial content: W-Ni-Fe  ,W-Ni-Cu



2. Physical properties of 95%W Tungsten Nickel Copper W-Ni-Cu Alloy Rod:



Grade 1 2 3 4
W content  (%) 90 92.5 95 97
Density (g/cm3) 16.85~17.25 17.15~17.85 17.75~18.35 18.25~18.85
Hardness  HRC (max.) 32 33 34 35
the maximum tensile strength ksi 110 110 105 100
  Mpa 758 758 724 689

Yield Strength

at 0.2% off set

ksi 75 75 75 75
  Mpa 517 517 517 517
Elongation % 5 5 3 2



3. Craft of 95%W Tungsten Nickel Copper W-Ni-Cu Alloy Rod:



Using high-purity raw materials, through pressing, sintering, forging, rolling, heat treatment, machining and other processes, processed into finished products.



4. Material characteristics of 95%W Tungsten Nickel Copper W-Ni-Cu Alloy Rod:



- Non-magnetic;



- Specific gravity: high density of ~18.8g/cm3;



- High strength: tensile strength is 600-900Mpa;



- Strong ray shielding ability: Under the same thickness, the ray shielding ability of tungsten alloy is more than 1.7 times that of lead.



- High thermal conductivity: tungsten alloy has a thermal conductivity that is five times that of die steel;



- Small thermal expansion coefficient: the thermal expansion coefficient of tungsten is 4~6×10-6/℃, only 1/2-1/3 of iron or steel;



- Good plasticity, workability and weldability;



- Compared with the toxicity of lead, tungsten alloy material has environmental protection properties, and it is not harmful to human safety when manufacturing radiation detectors with tungsten alloy shielding parts;



- In the field sensitive to magnetic environment, it exerts its special anti-interference advantage over tungsten-nickel-iron alloy.



5. Application of 95%W Tungsten Nickel Copper W-Ni-Cu Alloy Rod:



This kind of alloy is non-ferromagnetic and has relatively good electrical and thermal conductivity. It is often used in some special requirements, such as gyroscope rotors and other parts of devices and instruments that require work under the action of a magnetic field; electrical contacts of high-voltage electrical switches And some electrodes for electrical processing, etc.
