Thickness 0.5mm Molybdenum Rhenium Alloy Sheet Molybdenum Products For Semiconductor Industry Mirror Molybdenum Sheet

Place of Origin China
Brand Name PRM
Certification ISO9001
Model Number custom
Minimum Order Quantity 1kg
Price $60~280/kg
Packaging Details Plywood case
Delivery Time 7~10 work days
Payment Terms T/T
Supply Ability 2000kgs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Thickness 0.5mm Molybdenum Rhenium Alloy Sheet For Semiconductor Industry Material Molybdenum Rhenium Alloy
Type Mo-20%Re Mo-41%Re Mo-44.5%Re Mo-47.5%Re Mo Content Remain
Thickness 0.2mm Min. Width 10~350mm
Length ≤ 600mm MOQ 1kg
High Light

Semiconductor Molybdenum Products

,

0.5mm Molybdenum Products

,

Molybdenum Rhenium Sheet

Leave a Message
Product Description

Thickness 0.5mm Molybdenum Rhenium Alloy Sheet For Semiconductor Industry



1. Description of Molybdenum Rhenium Alloy Sheet 0.5mm:



Molybdenum-rhenium alloy rod is an alloy composed of metal molybdenum as matrix element and alloying element rhenium. The alloy exhibits a rhenium effect that improves plasticity, and the rhenium content in the alloy is generally 11% to 50% (mass fraction).



2. Size of Molybdenum Rhenium Alloy Sheet 0.5mm:



Name

Main Type

Main size(mm)

Molybdenum Rhenium Alloy Sheet

Mo-20%Re

Mo-41%Re

Mo-44.5%Re

Mo-47.5%Re

0.2min.×(10~350) ×600max.
Molybdenum Rhenium Alloy Foil 0.04min.×100×L





Other size and content rate,pls inquiry for us,we can custom.



Thickness 0.5mm Molybdenum Rhenium Alloy Sheet Molybdenum Products For Semiconductor Industry Mirror Molybdenum Sheet 0Thickness 0.5mm Molybdenum Rhenium Alloy Sheet Molybdenum Products For Semiconductor Industry Mirror Molybdenum Sheet 1



3. Performance Of Molybdenum Rhenium Alloy Sheet 0.5mm:



Rhenium can be added to molybdenum to increase its flexibility and strength. Molybdenum is a solid solution strengthening alloy. Adding 35% rhenium to molybdenum, the rolling deformation at room temperature can reach 90%. Molybdenum-rhenium alloys sheet are prepared by powder metallurgy. Mo-Re alloys are suitable for a variety of applications, including high-speed rotating X-ray tube targets, long-lasting grid plates for microwave communications, space reactor core heating tubes, high-temperature furnace heating elements, and high-temperature thermocouples.The room temperature tensile strength, ductility and resistivity of molybdenum-rhenium alloys increased with the increase of rhenium content. Mo-5%Re and Mo-41%Re are usually used as thermocouple wires for structural materials in aerospace. Mo-50%Re is used as high temperature structural material.





4. Production method Of Molybdenum Rhenium Alloy Sheet 0.5mm:





Molybdenum-rhenium alloy sheet are generally prepared by double sintering method, powder metallurgy method or medium temperature sintering method.



The process route of the double sintering method is as follows: mixing molybdenum powder and rhenium powder, pre-sintering under pressure and temperature rise, vacuum sintering, and finally sintering under the protection of hydrogen into a molybdenum-rhenium sintered ingot.



The process route of powder metallurgy is as follows: mix molybdenum powder and rhenium powder, then pre-sinter into molybdenum-rhenium pre-sintered ingot, and then sinter at high temperature into molybdenum-rhenium sintered ingot.



The process route of the medium temperature sintering method is as follows: firstly reduce molybdenum oxide to molybdenum powder, ammonium rhenate to rhenium powder, then mix the two by ball milling, and then pressurize and sinter molybdenum-rhenium sintered ingots under the mixing of inert gas and reducing gas. That's it.



Matters needing attention: No matter which preparation method is used, there are high requirements for the purity of molybdenum powder and rhenium powder.
